FireSmart Plus | Addressable Single Loop Fire Alarm Panel

Name: FireSmart Plus | Addressable Single Loop Fire Alarm Panel
Brand: Firesmart
Price: 476.22 GBP
Availability: InStock

£476.22

INC VAT

Code: FDS510/025

Have a question about this? Click here

Overview Features

Exclusive to Fire Detection Shop the FireSmart Plus addressable single loop fire alarm panel is a new direction in addressable fire alarm systems, powerful yet easy to install and configure.

Fully programmable via the on-board touchscreen display it is particularly suited for smaller commercial premises, HMO's and larger domestic properties.

Expandable to two loops via the optional loop card the FireSmart Addressable Plus can support upto 159 devices per loop.

Touch-screen colour display with selectable back-lit illumination and buttons
Intuitive colour event indication tab system for improved situational awareness
Simple Cause and Effect creator.
Quick configuration of the unit from the same display
On-screen 16 Virtual Zonal LED indicator to increase situational awareness.
Certified to EN54-2, EN54-4; LVD 62.368-1:2014+A11

Technical Specifications

Main Power Supply
100-240 V AC +/- 15%, 50 / 60 Hz
Power Consumptionmax. 65W
Battery Capacity7 Ah or 12 Ah (not included)
24 VDC outputmax. 500 mA
Outputs1 fault (NO/NC); 1 alarm (NO/NC)
Sounder output2, max. 50 mA
ColourRAL 9002
Protection classIP30
Dimensions ( H x W x D)356 x 379 x 120 mm
Operating temperature-5 C to +40 C
Humidity5% - 95% non-condensing
Weight1.76 kg
