The Fike Twinflex Pro 204-0012 Multipoint ASD Detector with Sounder and Strobe combines a multi-criteria detector, micro-processor control and integral sounder with beacon in one easy to install device requiring a single cable run.
7 modes of detection
Three sound patterns
Built in sounder
Base included
The Fike Twinflex Pro² 204-0012 Multipoint ASD Detector with Sounder and Strobe is a versatile, all-in-one fire detection device designed for seamless integration with the Twinflex Pro² two-wire fire alarm system.
It combines advanced multi-criteria detection, microprocessor control, and an integral sounder with a beacon, all within a single unit that requires only one cable run per zone.
This detector offers seven selectable modes, including three smoke detection settings, three heat detection settings, and one combination mode, allowing for adaptability in various environments.
The built-in sounder features three selectable sound patterns with an adjustable output ranging from 70dB to 90dB, ensuring clear and effective alarm signalling.
For ease of installation and configuration, the unit includes an in-built DIL switch for setting detection options and End of Line (EOL) selection. The device is supplied with a base, making it a practical and efficient solution for fire alarm installations.
Fike 204-0012
7 modes of detection (3 x smoke detection modes, 3 x heat detection modes & 1 x combination mode.)
In-built DIL switche to select option and EOL
3 sound patterns
Selectable 70 to 90db
Base included
Dimensions | 107mm diameter x 75mm |
Operating Temperature | -10°C to +50°C |
Operating Voltage Range | 18V to 32V DC |
Operating Current (Typical) | |
Quiescent | 56 µA |
End of Line ON (if applicable) | +50 µA |
(No Strobe Version) Alarm Sounding | |
Sounder High | 8.00 mA |
Sounder Low | 2.50 mA |
Sounder Off | 150 µA |
Alarm Activated (additional to Alarm Sounding) | 15.50 mA |
(Strobe Version) Alarm Sounding | |
Sounder High | 10.50 mA |
Sounder Low | 4.90 mA |
Sounder Off | 2.60 mA |
Alarm Activated (additional to Alarm Sounding) | 18.00 mA |
LED Operation | |
Detector in Normal State (Smoke) | Flash at 20-second intervals |
Detector in Normal State (Heat) | Double flash at 20-second intervals |
Detector at EOL | Flash at 5-second intervals |
Detector in Fault | Flash at 1.3-second intervals |
Detector Detecting Fire | Flash at 0.7-second intervals |
Detector in Fire (processed at panel) | Continuous |
Loading Units | V3 Panel / Pro Panel |
Max Loading Units per Zone | 27 SLU / 160 DLU |
(No Strobe Version) Sounder Load | |
Sounder High | 1.35 SLU / 8.0 DLU |
Sounder Low | 1.125 SLU / 6.5 DLU |
No Sounder | 0.5 SLU / 1.0 DLU |
(Strobe Version) Sounder Load | |
Sounder High | 2.7 SLU / 16.0 DLU |
Sounder Low | 1.35 SLU / 8.0 DLU |
No Sounder | 1.35 SLU / 8.0 DLU |
Volume Level (@ 1m anechoic, Dual Tone) | |
Sounder High | 90+ dB(A) |
Sounder Low | 70+ dB(A) |
Flammability | UL94-V2 |
IP Rating | IP21C |
Part Codes | |
No Sounder | 204-0003 |
With Sounder | 204-0001 |
With Sounder and Strobe | 204-0012 |
