ORDER NOW FOR DELIVERY FROM 03.04.25
The Fike Twinflex 204-0003 Multipoint ASD Detector combines a multi-criteria detector, micro-processor control, and base in one easy-to-install device on just one single cable run.
7 modes of detection
Base included
This product does not contain a sounder
The Fike Twinflex 204-0003 Multipoint ASD Detector is a versatile plug-in smoke detector that utilises a photoelectric sensing chamber to accurately measure smoke density.
It also features a thermistor sensing circuit for precise heat detection, allowing the device to be configured as a smoke, heat, or combined detector to suit different environments.
Designed exclusively for use with Twinflex Pro² Fire Alarm Panels and associated Fike Twinflex detection equipment, this intelligent detector ensures reliable performance and seamless integration. The unit includes a base for easy installation and operates efficiently on a single cable run, simplifying system setup.
With seven selectable detection modes, the Twinflex 204-0003 offers flexibility to meet varying fire detection requirements.
Fike 204-0003
7 modes of detection (3 x smoke detection modes, 3 x heat detection modes & 1 x combination mode.)
Selectable via in-built DIL
Selectable EOL
Base included
Removal tool required
This product does not contain a sounder
Model | Fike 204-0003 |
Dimensions | 107mm Diameter x 75mm |
Operating Temperature | -10°C to +50°C |
Operating Voltage Range | 18V to 32V DC |
Operating Current (Typical) | |
Quiescent | 56 µA |
End of Line ON (if applicable) | +50 µA |
(No Strobe Version) Alarm Sounding | |
Sounder High | 8 mA |
Sounder Low | 2.50 mA |
Sounder Off | 150 µA |
Alarm Activated (additional to Alarm Sounding) | 15.50 mA |
(Strobe Version) Alarm Sounding | |
Sounder High | 10.50 mA |
Sounder Low | 4.90 mA |
Sounder Off | 2.60 mA |
Alarm Activated (additional to Alarm Sounding) | 18.00 mA |
LED Operation | |
Detector in Normal State (Smoke) | Flash at 20-second intervals |
Detector in Normal State (Heat) | Double flash at 20-second intervals |
Detector at EOL | Flash at 5-second intervals |
Detector in Fault | Flash at 1.3-second intervals |
Detector Detecting Fire | Flash at 0.7-second intervals |
