Apollo 55000-401APO | XP95 High Temp 90°C Addressable Heat Detector

Name: Apollo 55000-401APO | XP95 High Temp 90°C Addressable Heat Detector
Brand: Apollo
Price: 31.56 GBP
Availability: InStock

Code: FDS600/029

£31.56

INC VAT

Code: FDS600/029

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

The Apollo 55000-401APO High-Temperature Heat Detector is designed for environments where higher temperature monitoring is essential. It is compatible with any addressable system using the Apollo protocol, making it an ideal choice for car parks, warehouses, hotels, retail, offices, and other areas where elevated temperatures could signal a potential fire risk.

This high-temperature detector is a CS-classified device, activating an alarm at 90°C. It offers fast and reliable detection in environments prone to higher temperatures, such as kitchens or industrial settings. The detector uses a thermistor to provide a proportional output to temperature changes, ensuring optimal performance and accuracy.

Built with a durable polycarbonate housing and nickel-plated stainless steel terminals, the 55000-401APO is designed to withstand challenging environments, ensuring long-lasting performance. Its IP53 rating protects the detector from dust and water ingress, making it suitable for a wide range of indoor applications.

Apollo 55000-401APO
High temperature version
Ideal in environments that are dirty or smoky under natural conditions
Well suited for warehouses, loading bays and car parks
Unaffected by wind or atmospheric pressure
Base supplied separately

Product Code	Apollo 55000-401APO
Warranty	10 years
Applications	Car parks, loading bays, dusty environments, warehouses, hotels, medium to large buildings, offices, restaurants, retail
Heat Classification	CS
Analogue Value Nominal	25
Analogue Value (- Tolerance)	2
Analogue Value (+ Tolerance)	2
Alarm Level Analogue Value	55
Colour	White
Weight	105g
Materials (Housing)	Polycarbonate
Materials (Terminals)	Nickel plated stainless steel
Product Length	42mm / 1.65in
Product Diameter	100mm / 3.94in
Standards	EN 54-5
Approvals	BOSEC, KRS, LPCB, CPR
Protocol Voltage	5 to 9V peak-to-peak
Protocol Voltage (Max)	9V
Protocol Voltage (Min)	5V
Power-Up Surge Current	1mA
Maximum Power-Up Time	4 seconds
Status Indicator (Alarm)	Red
Status Indicator (Fault)	Off
Quiescent Current	250μA
Quiescent Current Tested at	24V DC
Supply Voltage (Max)	28V DC
Supply Voltage (Min)	17V DC
Supply Voltage (Vmin-Vmax)	17 to 28V DC
Terminal Functions L2	+L2 Loop in & out positive, double terminal
Terminal Functions L1 In	-L1 in Loop in & out, double terminal
Terminal Functions +R	+R Remote indicator positive connection
Terminal Functions -R	-R Remote indicator negative connection
Polarity	L1 & L2 are polarity insensitive
Battery Powered	No
Humidity (Max)	95% RH
Humidity (Min)	0% RH
Humidity Note	No condensation or icing
Operating Temperature (Min - Max)	-20°C to 70°C (-4°F to 158°F)
IP Rating	IP53
Storage Temperature (Min - Max)	-30°C to 80°C (-22°F to 176°F)

Apollo 55000-401APO | XP95 High Temp 90C Addressable Heat Detector Data Sheet

Click here to download
