Code: FDS333/264
INC VAT
Code: FDS333/264
The Fike CIE-A-400 Addressable Fire Alarm Panel is supplied complete with loop card and can be easily expanded to a two loop panel.
Capable of supporting up to 400 devices with a maximum loop length of 2KM, the panel also provides two configurable monitored input circuits, 2 configurable monitored output circuits, 3 volt free relays and 2 fully configurable outputs. A Peripheral bus circuit to add up to 8 network or repeater panels.
The system may be configured utilising 3 alarm stages with full Zone to Zone Cause and Effect across all 32 panel zones with provision to include alarm confirmation and delay timers.
The CIE-A-400 control panel is compatible with the Fike addressable range of Detectors, Sounders and Call Points and utilises soft addressing principles eliminating the need for the installer to physically address each device whilst also eradicating time spent on faults caused by duplicate addressing.
Fike CIE-A-400
Single loop card expandable
All devices have built in isolators
Programmable monitored inputs and outputs
Event log holds up to 1000 events
Simple to use programming software
The operating parameters of the devices are configured either from the panel or via the OSP programming software and are then stored within the Flash memory of the device itself.
This enhanced digital protocol means less information is needed to be sent between the detector and the host control panel, resulting in faster, more reliable communication.
For new or upgrade to existing installations see our complete system builder tool
Fike CIE-A-400
Single loop card expandable
Surface or flush mount bezel options
All devices have built in isolators
Programmable monitored inputs and outputs
Event log holds up to 1000 events
Enhanced servicing and engineering tools
Intuitive End User interface
Uses Fike Multipoint Addressable detectors
Peripheral Bus for connecting up to 8 repeaters
Backward compatibility with existing Fike addressable systems
Surface mount as standard (flush mountable with additional cradle)
Specification | Details |
---|---|
Dimensions (WxHxD) | 353mm x 333mm x 117mm |
Operating Temperature | -5°C to +40°C |
IP Rating | IP30 |
Mains Supply Input | 230V AC Nominal |
Battery Requirement | 2 x 7/9Ah 12V Sealed Lead Acid (or 2 x 12/17Ah with extended battery box) |
Max Number of Loops | 2 loops |
Max Loop Length | 2000 metres |
Max Conductor Resistance | 24 Ohms |
Loop Loading | 450 DLU (200 Devices Max)* |
Loop Operating Voltage | 40V DC |
Standby Voltage | 24V DC |
Max Loop Current | 500mA |
Number of Zones | 32 |
LCD Display | LCD Graphical Display |
Device Labels | Up to 31 characters |
Event Log Capacity | 1000 events |
Max Repeater Panels | 8 panels |
Aux Power Output | 30V DC, 350mA |
Inputs | 2 x Monitored Inputs (3k3 EOL, 680R Firing Resistor) |
Outputs | 3 x Volt-Free Relay (30V DC @ 1A Max) |
Monitored Outputs | 2 x 32V DC @ 250mA Max (10k EOL) |
The Fike CIE-A-400 Addressable Fire Alarm Panel is supplied complete with loop card and can be easily expanded to a two loop panel.
Capable of supporting up to 400 devices with a maximum loop length of 2KM, the panel also provides two configurable monitored input circuits, 2 configurable monitored output circuits, 3 volt free relays and 2 fully configurable outputs. A Peripheral bus circuit to add up to 8 network or repeater panels.
The system may be configured utilising 3 alarm stages with full Zone to Zone Cause and Effect across all 32 panel zones with provision to include alarm confirmation and delay timers.
The CIE-A-400 control panel is compatible with the Fike addressable range of Detectors, Sounders and Call Points and utilises soft addressing principles eliminating the need for the installer to physically address each device whilst also eradicating time spent on faults caused by duplicate addressing.
Fike CIE-A-400
Single loop card expandable
All devices have built in isolators
Programmable monitored inputs and outputs
Event log holds up to 1000 events
Simple to use programming software
The operating parameters of the devices are configured either from the panel or via the OSP programming software and are then stored within the Flash memory of the device itself.
This enhanced digital protocol means less information is needed to be sent between the detector and the host control panel, resulting in faster, more reliable communication.
For new or upgrade to existing installations see our complete system builder tool
Fike CIE-A-400
Single loop card expandable
Surface or flush mount bezel options
All devices have built in isolators
Programmable monitored inputs and outputs
Event log holds up to 1000 events
Enhanced servicing and engineering tools
Intuitive End User interface
Uses Fike Multipoint Addressable detectors
Peripheral Bus for connecting up to 8 repeaters
Backward compatibility with existing Fike addressable systems
Surface mount as standard (flush mountable with additional cradle)
Specification | Details |
---|---|
Dimensions (WxHxD) | 353mm x 333mm x 117mm |
Operating Temperature | -5°C to +40°C |
IP Rating | IP30 |
Mains Supply Input | 230V AC Nominal |
Battery Requirement | 2 x 7/9Ah 12V Sealed Lead Acid (or 2 x 12/17Ah with extended battery box) |
Max Number of Loops | 2 loops |
Max Loop Length | 2000 metres |
Max Conductor Resistance | 24 Ohms |
Loop Loading | 450 DLU (200 Devices Max)* |
Loop Operating Voltage | 40V DC |
Standby Voltage | 24V DC |
Max Loop Current | 500mA |
Number of Zones | 32 |
LCD Display | LCD Graphical Display |
Device Labels | Up to 31 characters |
Event Log Capacity | 1000 events |
Max Repeater Panels | 8 panels |
Aux Power Output | 30V DC, 350mA |
Inputs | 2 x Monitored Inputs (3k3 EOL, 680R Firing Resistor) |
Outputs | 3 x Volt-Free Relay (30V DC @ 1A Max) |
Monitored Outputs | 2 x 32V DC @ 250mA Max (10k EOL) |
