Apollo SA4700-103APO | Intelligent Mains Switching Input/Output Unit

Name: Apollo SA4700-103APO | Intelligent Mains Switching Input/Output Unit
Brand: Apollo
Price: 69.54 GBP
Availability: InStock

£69.54

INC VAT

Code: FDS100/422

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

Backwards compatible with Apollo XP95 or Discovery protocols the SA4700-103APO is Apollo CoreProtocol ready and replaces the Apollo 55000-875APO.

Featuring Apollo's new "Faceplate style" enclosure, the Apollo SA4700-103APO can be mounted in the supplied back-box or flush mounted using a standard double gang recessed 30mm box.

The SA4700-103APO Intelligent Input/Output Unit provides a voltage-free, double pole changeover (DPCO) relay output, and a monitored switch input.

Apollo SA4700-103APO
Supervises one or more normally-open switches connected to a single pair of cables
Three visible LEDs
Capable of switching 250V AC at up to 5A

Colour	White
Weight	301g
Product Length	60mm (2.36in)
Product Width	150mm (5.91in)
Product Depth	90mm (3.54in)
Approvals	FG, LPCB, SBSC, BOSEC, VdS, CPR
Humidity	0% to 95% RH (no condensation or icing)
Operating Temperature	-40 to 70°C (-40 to 158°F)
Operating Temperature (Max)	70°C (158°F)
Operating Temperature (Min)	-40°C (-40°F)
IP Rating	IP54

Apollo SA4700-103APO | Intelligent Mains Switching Input/Output Unit Data Sheet

Click here to download
