Code: FDS340/035
INC VAT
Code: FDS340/035
The Twinflex Hipoint unit allows for audible indication when the system enters an alarm condition.
This device is compatible with the Twinflex 2-wire range of Fire Alarm equipment and comprises a 2-wire zone-powered sounder.
This device may be installed on the same zone as the Multipoint detector/sounder and associated Twinflex devices
Fike 302-0004
Suitable for indoor & outdoor applications
IP55 rated
90dB output
Three sound patterns
Inbuilt 'End of Line' set by a DIL switch
Supplied with backbox & flush adaptor plate
Feature | Specification |
---|---|
Dimensions | |
Width | 123mm |
Height | 130mm |
Depth | 101mm |
Operating Temperature | -10°C to +50°C |
Voltage Ranges | |
DC Output from Mains Powered Panel | 25.5 to 35V DC |
DC Output from Battery Powered Panel | 20 to 26V DC |
Operating Current (Typical) | |
Quiescent | 185 uA |
End of Line ON (if applicable) | 175 uA (in addition to Quiescent) |
Alarm Sounding - Sounder High | 14.5 mA |
Alarm Sounding - Sounder Low | 12.6 mA |
Loading Units | |
Max Loading Units per Zone | 27 SLU (V3 Panel) / 160 DLU (Pro/Pro2 Panel) |
Sounder High | 2.5 SLU (V3 Panel) / 14.5 DLU (Pro/Pro2 Panel) |
Sounder Low | 2.0 SLU (V3 Panel) / 13.0 DLU (Pro/Pro2 Panel) |
Sounder High | 90+ dB(A) |
Sounder Low | 65+ dB(A) |
Flammability | UL94-V2 |
IP Rating | IP 55* |
Part Code | 302 0004 |
*Not EN54-3 compliant |
The Twinflex Hipoint unit allows for audible indication when the system enters an alarm condition.
This device is compatible with the Twinflex 2-wire range of Fire Alarm equipment and comprises a 2-wire zone-powered sounder.
This device may be installed on the same zone as the Multipoint detector/sounder and associated Twinflex devices
Fike 302-0004
Suitable for indoor & outdoor applications
IP55 rated
90dB output
Three sound patterns
Inbuilt 'End of Line' set by a DIL switch
Supplied with backbox & flush adaptor plate
Feature | Specification |
---|---|
Dimensions | |
Width | 123mm |
Height | 130mm |
Depth | 101mm |
Operating Temperature | -10°C to +50°C |
Voltage Ranges | |
DC Output from Mains Powered Panel | 25.5 to 35V DC |
DC Output from Battery Powered Panel | 20 to 26V DC |
Operating Current (Typical) | |
Quiescent | 185 uA |
End of Line ON (if applicable) | 175 uA (in addition to Quiescent) |
Alarm Sounding - Sounder High | 14.5 mA |
Alarm Sounding - Sounder Low | 12.6 mA |
Loading Units | |
Max Loading Units per Zone | 27 SLU (V3 Panel) / 160 DLU (Pro/Pro2 Panel) |
Sounder High | 2.5 SLU (V3 Panel) / 14.5 DLU (Pro/Pro2 Panel) |
Sounder Low | 2.0 SLU (V3 Panel) / 13.0 DLU (Pro/Pro2 Panel) |
Sounder High | 90+ dB(A) |
Sounder Low | 65+ dB(A) |
Flammability | UL94-V2 |
IP Rating | IP 55* |
Part Code | 302 0004 |
*Not EN54-3 compliant |
