Input and Output |
Wireless Protection Zone | Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs) |
Port |
Buzzer | Hub: Built-in |
Button | Hub: 1 × reset, 1 × power, 1 × AP
Keyfob: 4 (Home, Away, Disarm, and SOS)
Door Detector: 1 × power button
PIR Detector: 1 × power button |
Indicator Light | Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)
Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)
Door Detector: 1 × green alarm indicator
PIR Detector: 1 × green alarm indicator |
Storage battery | Hub: Built-in lithium battery |
Network Mode | Hub: Ethernet, Wi-Fi and Cellular network (Supports installation of dual SIM cards. Only one card can be enabled at a time) |
Network Port | Hub: 1 × RJ-45 10 M/100 M Ethernet port |
Function |
Network Protocol | Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP |
Offline Cache | Hub: Max. 50 entries (ANR) |
Power Failure Protection for Configured Parameters | Hub: Yes |
Remote Update | All: Cloud update |
Video Linkage | Hub: Yes |
SMS | Hub: Yes (up to 5 phone numbers) |
Phone Call | Hub: Yes (up to 5 phone numbers) |
Low Battery Alarm | All: Yes |
Tamper Alarm | Hub: Yes
Door Detector: Yes
PIR Detector: Yes |
User Management | Hub: Share function for App users |
Search | Hub: Searching push messages, device status, and program version. Detecting signal strength.
Keyfob: Signal strength detection
Door Detector: Signal strength detection
PIR Detector: Signal strength detection |
Arm and Disarm | Hub: App; keyfob; schedule |
Wireless |
Carrier Frequency | All: 868.0 MHz–868.6 MHz |
Transmitter Power (EIRP) | All: Limit 25 mW |
Communication Distance | Hub: Up to 2,000 m (6,561.68 ft) in an open space
Keyfob: Up to 900 m (2,952.76 ft) in an open space
Door Detector: Up to 1,200 m (3,937.01 ft) in an open space
PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space |
Communication Mechanism | All: Two-way |
Encryption Mode | All: AES128 |
Frequency Hopping | All: Yes |
Wi-Fi |
Wi-Fi Standard | IEEE 802.11b/g/n |
Wi-Fi Frequency Range | 2400-2483.5 MHz |
Wi-Fi Power Transmission | ≤20 [email protected] MHz |
Cellular Network |
Cellular Network Standard | GSM/WCDMA/LTE |
Frequency Range | GSM: 1,800/900 MHz; |
Transmitter Power (EIRP) | Power class0: 30 dBm±3 dB (GSM900)
Power class5: 33 dBm±3 dB (GSM1800) |
Peripherals |
External Zone | Door Detector: 1-channel dry contact input |
Temperature |
Measuring Range (Temperature) | Door Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
PIR Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor) |
Measuring Precision (Temperature) | Door Detector: ± 1 °C (± 33.8 °F)
PIR Detector: ± 1 °C (± 33.8 °F) |
Resolution (Temperature) | Door Detector: 1 °C (33.8 °F)
PIR Detector: 1 °C (33.8 °F) |
Specification |
Sensor | Door Detector: Reed switch
PIR Detector: Dual elements low-noise PIR sensor |
Test Mode | Door Detector: Yes
PIR Detector: Yes |
Scenario | Door Detector: Non-metal doors |
Movement Distance | Door Detector: < 40 mm (1.57") |
Detection Mode | PIR Detector: PIR |
Detection Range | PIR Detector: 12 m (39.37 ft) (90°) with installation height of 2.2 m (7.21 ft) |
Detection Speed | PIR Detector: 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s) |
Pet Immunity Level | PIR Detector: ≤ 18 kg (39.68 lb) |
White Light Resistance Level | PIR Detector: 6500 lx |
Two-way Digital Temperature Compensation | PIR Detector: Yes, no attenuation of detection distance in high temperature |
Sensitivity | PIR Detector: 3 levels adjustable |
General |
Power Supply | Hub: 12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)
Keyfob: CR2032 battery
Door Detector: CR123A battery
PIR Detector: CR123A battery |
Battery Life | Hub: Storage battery standby for 12 Hours
Keyfob: 5 years
Door Detector: 5 years
PIR Detector: 4 years |
Power Consumption | Keyfob: Max. 85 mW
Door Detector: Max. 70 mW
PIR Detector: Max. 75 mW |
Operating environment | Hub: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)
Keyfob: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Door Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
PIR Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
Operating Humidity | All: 10%–90% (RH) |
Product Dimensions | Hub: 163.0 mm × 163.0 mm × 32.0 mm (6.42"" × 6.42"" × 1.26"") (L × W × H)
Keyfob: 60.0 mm × 39.5 mm × 15.0 mm (2.36"" × 1.56"" × 0.59"") (L × W × H)
Door Detector: 100.2 mm × 20.8 mm × 20.3 mm (3.94"" × 0.82"" × 0.80"") (L × W × H)
PIR Detector: 104.0 mm × 60.0 mm × 50.0 mm (4.09"" × 2.36"" × 1.97"") (L × W × H) |
Packaging Dimensions | Hub: 219.0 mm × 187.0 mm × 91.0 mm (8.62"" × 7.36"" × 3.58"") (L × W × H)
Keyfob: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H)
Door Detector: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H)
PIR Detector: 135.0 mm × 98.5 mm × 56.8 mm (5.31"" × 3.88"" × 2.24"") (L × W × H) |
Installation | Hub: Wall mount; Desktop
Door Detector: Bracket mount
PIR Detector: Wall mount |
Net Weight | Hub: 0.38 Kg (0.84 lb)
Keyfob: 20 g (0.04 lb)
Door Detector: 70 g (0.15 lb)
PIR Detector: 100 g (0.22 lb) |
Gross Weight | Hub: 0.8 Kg (1.76 lb)
Keyfob: 65 g (0.14 lb)
Door Detector: 115 g (0.25 lb)
PIR Detector: 170 g (0.37 lb) |
Casing | All: PC + ABS |
Certifications | All: CE |
