C-TEC BF430A/CX Wall Sounder | XP95 Compatible | Addressable

Name: C-TEC BF430A/CX Wall Sounder | XP95 Compatible | Addressable
Brand: C-tec
SKU: FDS410/106
Price: 43.2 GBP
Availability: InStock

Code: FDS410/106

£43.20

INC VAT

Code: FDS410/106

Product Type (Categories) System Base

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

The C-TEC BF430A/CX wall sounder is compatible with all Apollo XP95/Discovery addressable fire panels and is fully certified to EN54-3 & 17.

TURES Compatible with all XP95 protocol panels

Third-party certified to EN54-3 (Sounders) and 17 (Isolators) by the LPCB.
Impressive 103dB(A) sound output @ 1m.
Onboard short-circuit loop isolator.
550A quiescent current.
5mA alarm current @24V DC (sounder on max).
Group addressing facility allows multiple devices to be operated simultaneously.
7 selectable volume levels and up to 15 selectable tone pairs.
IP33C (Type A) rated.

Supply/operating voltage: 17 to 28V DC.
Quiescent current: 550A @ 24 VDC.
Nominal SPL (Sound Pressure Level): 103dB(A) when set to tone 1.
Alarm current: 5mA (Sounder on max).
Indicators: Polling (green LED) & Short Circuit Isolator Active (amber LED).
Product dimensions (mm): 114mm diameter x 131mm deep.
IP Rating: IP33C (Type A).
Weight: 300g.
Operating conditions/temperature: -10C to +55C. Max. 95% RH (Non-condensing).

C-TEC BF430A/CX Wall Sounder | XP95 Compatible | Addressable Data Sheet

Click here to download
