Code: FDS100/436
INC VAT
Code: FDS100/436
The Apollo 55400-894APO AlarmSense Manual Call Point has push button operation and a redesigned reset mechanism. Fully compliant with EN54-11. AlarmSense by Apollo is a range of detectors, sounders and accessories designed to be connected to a single cable, saving time and money while simplifying the installation process.
The AlarmSense Manual Call Point has been designed to operate on a loop of AlarmSense compatible two wire fire alarm systems. An alarm is initiated by pressing the resettable element.
The manual call point signals to the Control and Indicating Equipment using zener voltages. An alarm status is indicated through the rotation of the resettable element, displaying yellow and black indication bars and a solid red LED. The manual call point can be easily reset from the front using the supplied reset key
A protective Perspex cover is also available.
Apollo 55400-894APO
Re-settable element
Red LED to signal alarm
Compliant with EN54:11
Flush or surface mount
Protective cover available separately
Technical Data | Specifications |
---|---|
Supply Voltage | 9-33V DC |
Current Consumption (max) at 24V DC | |
Quiescent | 50µA |
Alarm Current (LED On) | 1.5mA |
Operating Temperature | -40°C to 70°C |
Humidity | 0% to 95%RH (no condensation or icing) |
Vibration, Impact & Shock | EN 54-11 |
IP Rating | IP44 |
Approvals & Standards | EN 54-11 |
Dimensions | 90mm height x 90mm width x 63mm depth |
Weight | 156g |
The Apollo 55400-894APO AlarmSense Manual Call Point has push button operation and a redesigned reset mechanism. Fully compliant with EN54-11. AlarmSense by Apollo is a range of detectors, sounders and accessories designed to be connected to a single cable, saving time and money while simplifying the installation process.
The AlarmSense Manual Call Point has been designed to operate on a loop of AlarmSense compatible two wire fire alarm systems. An alarm is initiated by pressing the resettable element.
The manual call point signals to the Control and Indicating Equipment using zener voltages. An alarm status is indicated through the rotation of the resettable element, displaying yellow and black indication bars and a solid red LED. The manual call point can be easily reset from the front using the supplied reset key
A protective Perspex cover is also available.
Apollo 55400-894APO
Re-settable element
Red LED to signal alarm
Compliant with EN54:11
Flush or surface mount
Protective cover available separately
Technical Data | Specifications |
---|---|
Supply Voltage | 9-33V DC |
Current Consumption (max) at 24V DC | |
Quiescent | 50µA |
Alarm Current (LED On) | 1.5mA |
Operating Temperature | -40°C to 70°C |
Humidity | 0% to 95%RH (no condensation or icing) |
Vibration, Impact & Shock | EN 54-11 |
IP Rating | IP44 |
Approvals & Standards | EN 54-11 |
Dimensions | 90mm height x 90mm width x 63mm depth |
Weight | 156g |
