Apollo 55000-812APO | Addressable Din Rail Zone Monitor with Isolator

Name: Apollo 55000-812APO | Addressable Din Rail Zone Monitor with Isolator
Brand: Apollo
Price: 81.3 GBP
Availability: InStock

Code: FDS340/773

£81.30

INC VAT

Code: FDS340/773

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

The Apollo 55000-812APO is a compact, DIN-rail-mounted mini switch monitor module designed to interface with external devices such as door contacts or flow switches in an XP95 or Discovery fire alarm system. It enables seamless integration by monitoring volt-free contacts and reporting status changes to the control panel.

With an IP20 rating, this module is ideal for indoor applications and offers reliable performance in a wide temperature range (-20°C to 70°C). It meets EN 54-17 and EN 54-18 standards, ensuring compliance with industry requirements. Its 10-year warranty guarantees long-term reliability.

Apollo 55000-812APO
Apollo XP95 or Discovery protocol
Max 20 Apollo conventional detectors
Loop-Powered
Din rail mount

Apollo 55000-812APO
Warranty	10 years
Colour	Green
Weight	95g
Product Length	110mm (4.33in)
Product Width	107mm (4.21in)
Product Depth	20mm (0.79in)
Standards	EN 54-17, EN 54-18
Approvals	FG, LPCB, CPR
Supply Voltage (Min - Max)	17 to 28V DC
Maximum Power-Up Time	4 seconds
Humidity	0% to 95% RH (no condensation/icing)
Operating Temperature (Min - Max)	-20 to 70°C (-4 to 158°F)
IP Rating	IP20

Apollo 55000-812APO | Addressable Din Rail Zone Monitor with Isolator Data Sheet

Click here to download

Overview

Features

Technical Data

Apollo 55000-812APO
Warranty	10 years
Colour	Green
Weight	95g
Product Length	110mm (4.33in)
Product Width	107mm (4.21in)
Product Depth	20mm (0.79in)
Standards	EN 54-17, EN 54-18
Approvals	FG, LPCB, CPR
Supply Voltage (Min - Max)	17 to 28V DC
Maximum Power-Up Time	4 seconds
Humidity	0% to 95% RH (no condensation/icing)
Operating Temperature (Min - Max)	-20 to 70°C (-4 to 158°F)
IP Rating	IP20
